PRICE: $250.00 (O.B.O) - Shipping Included
This Amateur HF transceiver was owned, and built, by now silent key, ABØM. It is in beautiful shape and the price includes shipping to the continental US. It was in good working condition when taken out of service. Unfortunately that is all we know about the unit. Radio comes with matching power supply.
The Heathkit Model HW-8 Transceiver is a solid-state, four-band QRP (low power) unit covering the CW portion of the eighty, forty, twenty, and fifteen meter amateur bands. The direct-conversion receiver features an RF stage, a balanced product detector, and an active audio filter wide or narrow selectivity.
Other features include diode band switching which is controlled by pushbuttons and a method of premixing the variable and heterodyne oscillator signals to provide the same dial read-out on all bands. This also provides excellent stability and a fixed frequency offset on all bands while you are transmitting.
In addition to indicating Relative Power, the panel meter is used during alignment to assure proper adjustment of the transmitter tuned circuits.
The HW-8 Transceiver may be operated from the Heathkit Accessory Power Supply Model HWA-7-1, an equivalent low impedence power supply, or from batteries.
80 meters, 3.5 to 3.75 MHz
40 meters, 7.0 to 7.25 MHz
20 meters, 14.0 to 14.25 MHz
15 meters, 21.0 to 21.25 MHz
Frequency Stability: Less than 150Hz/hour drift after 60 minute warm-up
Frequency Generation: Premixed VFO and HFO
Power Requirements: 13.4 volts DC, nominal. 90mA receive mode and 430 mA transmit mode
Dimensions: 9-¼" wide x 8-½" deep x 4-¼" high, including knobs and feet
(23.5cm wide x 21.6 cm deep x 10.8cm high)
Weight: 4 lbs. (1.8kg)
DC Power Input:
80 meters -- 3.5 watts
40 meters -- 3.0 watts
20 meters -- 3.0 watts
15 meters -- 2.5 watts
Frequency Control: Built-in VFO
Output Impedence: 50 ohms unbalanced
Sidetone: Built-in, adustable volume
Spurious and Harmonic Levels: At least 35dB down
Transmit Frequency Offset: Approximately 750 Hz lower, fixed on all bands
Receiver Type: Direct conversion with RF amplifier, balanced product detector, and active audio filter
Sensitivity: 1 microvolt or less for 10dB (S+N)/N 0.2 microvolt provides readable signal
Selectivity: Wide -- 750 Hz at 6dB down
Narrow -- 375 Hz at 6dB down
Passband Center Frequency: 750 Hz
Type of Reception: CW
Audio Output Impedance: 1000 ohms nominal
